Bearings Data
| Inner diameter Ø (mm): | 17 |
| Bore Dia Tolerance-Ø (mm): | 0,015/0 |
| Width Radial Insert Bearing To The Slot e (mm): | 76 |
| Width Radial Insert Bearing a (mm): | 89 |
| Shaft Fastening: | Grub Screws |
| Housing Type: | Radial Insert Ball Bearing |
| Grub Screw: | M6 |
| Bearing No.: | UC 203 |
| Housing No.: | T 204 |
| Ring Material: | Rolling bearing steel |
| Rolling Element Material: | Rolling bearing steel |
| Cage Material: | Sheet Steel |
| Housing Material: | Cast Iron |
| Number of Mounting Holes: | 1 |
| Width Tolerance Bi (mm): | 0/-0,12 |
| Mass: | 0,7600 kg |
Radial Insert Ball Bearings Housing Unit UCT203 – Shaft: 17 mm
