Bearings Data
| Inner diameter Ø (mm): | 90 |
| Bore Dia Tolerance-Ø (mm): | 0,028/0 |
| Shaft Fastening: | Grub Screws |
| Housing Type: | Flange |
| Grub Screw: | M16 |
| Bearing No.: | UC 318 |
| Housing No.: | F 318 |
| Ring Material: | Rolling bearing steel |
| Rolling Element Material: | Rolling bearing steel |
| Cage Material: | Sheet Steel |
| Housing Material: | Cast Iron |
| Recommended tightening torque for housing attachment (Nm): | 64 |
| Number of Mounting Holes: | 4 |
| Width Tolerance Bi (mm): | 0/-0,2 |
| Mass: | 18,8000 kg |
Flange Bearings / Flange Housing Unit UCF318 – Shaft: 90 mm
