Bearings Data
| Inner diameter Ø (mm): | 45 |
| Outer diameter Ø (mm): | 100 |
| Width (mm): | 30 |
| Bore Dia Tolerance-Ø (mm): | 0,021/0 |
| Outer Dia Tolerance-Ø (mm): | 0/-0,015 |
| Width Tolerance (mm): | 0/-0,12 |
| Rows: | single row |
| Shaft Fastening: | Grub Screws |
| Grub Screw: | M10 |
| Extended Inner Ring: | both sides |
| Seals: | 2-peace sealing system |
| Ring Material: | Rolling bearing steel |
| Rolling Element Material: | Rolling bearing steel |
| Cage Material: | Sheet Steel |
| Recommended tightening torque for housing attachment (Nm): | 22 |
| Magnetic: | yes |
| Mass: | 1,3500 kg |
Radial Insert Ball Bearings UC309 – Shaft: 45 mm
