UC203 Hybrid Ceramic Insert Bearings
UC203 Hybrid Ceramic Insert Bearings have expanded inner rings for easier fixing on shafts that held in position on the shaft by two set screws which are directly on the extended end of the inner ring.
If you need other Ceramic Ball Bearing click on the REQUEST QUOTE button.
Description
Specifications
UC203 Hybrid Ceramic Insert Bearings
Bore Type: Cylindrical bore
Bore Size d: 17 mm
Bearing Material: 52100 Chrome Steel
Ball Material: Silicon Nitride (Si3N4)
In stock items will typically ship in 10 to 13 working days.
Large quantity discounts available.
Dimensions
| Outside Diameter D | 47.000 mm |
| Inside Ring Width B | 31.000 mm |
| Outside Ring Width C | 16.000 mm |
| Radius r | 0.6 mm |
| Groove Position C1 | 3.90 mm |
| Center of Bearing from End S | 12.7 mm |
| Dimension S1 | 18.30 mm |
| Set Screw Distance S2 | 5.00 mm |
| Set Screw Size | M6×0.75 |
| Number of Set Screws | 2 |
Load Ratings
| Static Load Rating | 6650 N |
| Dynamic Load Rating | 12800 N |
