6204 Hybrid Ceramic Bearings (20X47X14)
FIJ’s 6204 Hybrid spindle bearings are used to meet the requirements of particularly demanding applications. The inner ring and outer ring are made of either Chrome Steel 52100 or Stainless Steel 440C while the balls are ceramic (Si3N4).
Description
6204 Hybrid Ceramic Bearings (20X47X14)
| Dimension Type | Metric |
|---|---|
| ID (d) | 20 |
| OD (D) | 47 |
| Width (B1) | 14 |
Calculation data
| Basic dynamic load rating | C | 13.5 | kN | |
| Basic static load rating | C0 | 6.55 | kN | |
| Limiting speed | 17000 | r/min |
In stock items will typically ship in 3 to 7 working days.
Large quantity discounts available.
We Build Your Bearings By Hand
At FIJ we build every single bearing by hand for your specific custom application, we do not sale pre-built, machine made bearings. All the ceramic material for full ceramic and hybrid ceramic bearing are made in our own facility. Please note, our Chrome Steel 52100, Stainless Steel 440C, Cage/Retainer and Enclosure components are made in Japan and Taiwan, to our specs.
